Create Series Power Socket OM-1A1U1C

This is a standard power strip with USB charging. One AC outlets, a standard USB-A port and a tech-forward USB-C port make this power strip do a excllent performace in commercial and Residential accasions.
Smart power distribution technology balances power delivery to devices based on the ports in use, preventing overcharging and short-circuiting.

  • Power Sockets + 1 USB + 1 Type-C

  •  Installation option: side clamp for easy, quick, and tool-free installation
  • ABS+PC Fire Retardant
  •  Color: White, Black, Grey or customized
  • Customized support: Prototype design, Logo, Color, Package
  • Certification: CE,UL,ROHS FCC
Availability:
Quantity:
  • OM-1A1U1C
  • OMNI
SPECIFICATIONS

PortsAC Outlets1xNEMA 5-15R
USB Ports1xUSB-A, lxUSB-C



Electrical RatingInput Voltage120VAC,60Hz,(12A max)
USB PortsConnected to one of the two ports
1) USB-A:5V/3A,9V/2A,12/1.5A (15W max)
2) USB-C:5V/3A,9V/2.2A,15V/1.4A,20V/1.25A (25W max)
Both ports connected
USB-A: 5V/1.5A (10W max)
USB-C: 5V/2.0A ( 10W max)



CordLength58'(172.7cm)



EnvironmentalTemperature Operating0°-30°
Temperature Operating Storage10°-50°
Certification
UL, UK, EU
